Growatt MOD 10KTL3-X2 Pro 10kW On-Grid Inverter (IP66)

Growatt MOD 10KTL3-X2 Pro is a 10kW three phase grid-tied inverter for homes and businesses that want to cut electricity bills with solar and send extra power back to the grid. It has no battery, so it is the simpler and lower-cost way to go solar. It reaches 98.6% maximum efficiency, and its input window of 140V to 1000V with a start voltage of only 160V helps it start generating early in the morning and keep going late in the afternoon. It can take up to 15,000W of PV power on a 10kW output. Type II surge protection on both the DC and AC side and string monitoring are included, and AFCI arc fault protection is optional. The IP66 enclosure resists dust and strong water jets, and the unit weighs just 14.6kg, which makes wall mounting easier.

• At Sensato Trade you get original products with delivery across Pakistan. If you want to explore more options in this Growatt MOD 10KTL3-X2 Pro 10kW On-Grid Inverter, visit Sensato Trade platform.

Growatt On-Grid Inverter 10kW - Key Features

• 10kW nominal power on a three phase output
• 98.6% maximum efficiency
• IP66 protection rating
• Type II SPD on both DC and AC side
• String monitoring, with optional AFCI
• OLED display and touch button, plus Wi-Fi and app monitoring
• Altitude rating up to 4000m
• Power consumption below 1W

Growatt On-Grid Inverter 10kW - Technical Specifications

• Brand: Growatt
• Model: MOD 10KTL3-X2 (Pro)
• Type: three phase PV on-grid inverter
• Nominal power: 10,000W
• Maximum PV power: 15,000W
• Maximum DC voltage: 1100V
• Voltage range: 140V to 1000V
• Start voltage: 160V
• Maximum output current: 16.7A
• AC voltage: 220V/380V or 230V/400V (340 to 440V)
• Maximum efficiency: 98.6%
• Topology: transformerless
• Protection: IP66
• Operating temperature: –25°C to +60°C
• Weight: 14.6kg
• Dimensions: 425 × 387 × 178mm
• Display: OLED + LED / Wi-Fi + app

Who Should Buy This Inverter?

• Homes and businesses with a three phase connection
• Buyers who want to lower electricity bills without buying a battery
• Net metering customers who plan to export extra power
• Roofs with two separate arrays, thanks to multiple MPPT inputs
• Installers who want a lightweight inverter that is easy to lift and mount
• Buyers who want strong surge protection built in

On-Grid vs Hybrid: Which One Do You Need?

An on-grid inverter works only while the utility grid is present, which is how most grid-tied systems are designed. If the grid goes down, it shuts off for safety, so it will not give you backup power. A hybrid inverter adds a battery, which costs more but keeps your loads running during an outage. If your main goal is a lower bill and your power cuts are short, an on-grid inverter like this one is the cost-effective option. If outages are frequent and long, consider a hybrid model instead.

Growatt On-Grid Inverter 10kW - Compatibility and Installation Guide

• Confirm that you have a three phase 400V supply
• Keep the string voltage inside the 140V to 1000V window
• Do not exceed the 15,000W maximum PV power
• Use correctly sized DC and AC cables and check polarity
• Follow the manual for earthing and the Wi-Fi setup
• Installation should be done by a qualified solar installer

Frequently Asked Questions

What is the rated power?
10kW.

How efficient is it?
98.6% maximum.

Does it need a battery?
No, it is an on-grid inverter.

Will it work in a power cut?
No. On-grid inverters shut down when the grid is off.

What is the IP rating?
IP66.

How much does it weigh?
About 14.6kg.
